Conductor network
TSC-0912 - 09.10.12
Conductor
diameter
Conductor
material
Weight Part
each No.
For use with solid circular conductor
8 mm Copper 0.01 kg CP905
8 mm Aluminium 0.01 kg CP925
10 mm* Copper 0.01 kg CP915
10 mm* Aluminium 0.01 kg CP935
For use with stranded conductor
50 mm 2 Copper 0.01 kg CP910
70 mm 2 Copper 0.01 kg CP915
95 mm 2 Copper 0.01 kg CP920
* PVC covered 8 mm conductor.
Manufactured from pure copper or aluminium, these pressed clips are
available to suit bare and PVC covered copper and aluminium solid circular
conductor, and bare copper stranded conductor.
One hole cable clip
Manufactured from high quality copper and aluminium alloys for excellent
corrosion resistance and high pull off loads.
Fix using countersunk wood screws 11⁄2” No. 10 or M6 (Part no.
SW005 or SW105) and wall plugs (Part no. PS305) - see Accessories
page 72.
CP915
CP815
Fix using roundhead wood screws 11⁄2” No. 10 or M6 (Part no.
SW305 or SW405) and wall plugs (Part no. PS305) - see Accessories
page 72.
Conductor
diameter
Conductor
material
Weight Part
each No.
For use with solid circular conductor
8 mm Copper 0.09 kg CP805
8 mm Aluminium 0.03 kg CP806
10 mm* Copper 0.10 kg CP815
10 mm* Aluminium 0.04 kg CP816
For use with stranded conductor
50 mm 2 Copper 0.10 kg CP810
70 mm 2 Copper 0.10 kg CP815
95 mm 2 Copper 0.10 kg CP835
* For use with PVC covered 8 mm conductor or for supporting air terminals when used in conjunction with
wall mounted air rod bases. Can also be used with glazing bar holdfast and back plate holdfast stem
(see page 63).
Heavy duty cast cable saddle
