Conductor network
TSC-0912 - 09.10.12
Fix using countersunk wood screws 11⁄
2” No. 10 or M6 (Part no.
SW005 or SW105) and wall plugs (Part no. PS305 ) - see Accessories
page 72.
Conductor
size
Weight Part
each No.
For use with bare copper
20 x 3 mm 0.06 kg CP205
25 x 4 mm 0.07 kg CP216
30 x 5 mm 0.10 kg CP227
38 x 5 mm 0.12 kg CP245
40 x 4 mm 0.14 kg CP241
50 x 4 mm 0.15 kg CP256
For use with PVC covered copper
25 x 3 mm 0.10 kg CP215
25 x 6 mm 0.13 kg CP225
50 x 6 mm 0.26 kg CP265
For use with lead covered copper
25 x 3 mm 0.20 kg CP305
For use with bare aluminium
20 x 3 mm 0.02 kg CP105
50 x 6 mm 0.05 kg CP125
For use with PVC covered aluminium
25 x 3 mm 0.04 kg CP115
50 x 6 mm 0.06 kg CP130
Tape clip
Manufactured from high quality copper or aluminium alloys.
Manufactured from pure copper or aluminium, these pressed clips are
available in a range of sizes to suit bare and PVC covered copper and
aluminium tapes.
DC tape clip
Fix using roundhead wood screws 11⁄2” No. 10 or M6 (Part no.
SW305 or SW405 and wall plugs (Part no. PS305) - see Accessories
page 72.
CP205
CP515
Conductor
size
Weight Part
each No.
For use with bare copper
20 x 3 mm 0.02 kg CP510
25 x 3 mm 0.02 kg CP515
For use with bare aluminium
20 x 3 mm 0.01 kg CP405
25 x 3 mm 0.01 kg CP410
25 x 6 mm 0.01 kg CP415
For use with PVC covered tape
25 x 3 mm 0.02 kg CP517
IEC/BS EN 62561-4 (CP215, CP115)
