Furse Total Solution to Earthing & Lightning Protection

54 / 300

Furse, Wilford Road, Nottingham, NG2 1EB • Tel: +44 (0)115 964 3700 • Email: • Web:
TSC-0912 - 09.10.12
Conductor network
Fix using countersunk wood screws 11⁄
2” No. 10 or M6 (Part no.
SW005 or SW105) and wall plugs (Part no. PS305 ) - see Accessories
page 72.
Conductor
size
Colour Weight Part
each No.
For use with bare tape
20 x 3 mm Brown 0.01 kg CP005
20 x 3 mm Grey 0.01 kg CP010
25 x 3 mm Brown 0.01 kg CP015
25 x 3 mm Grey 0.01 kg CP020
38 x 5 mm Brown 0.01 kg CP060*
50 x 6 mm Brown 0.02 kg CP065*
For use with PVC covered tape
25 x 3 mm Brown 0.01 kg CP025
25 x 3 mm Black 0.01 kg CP030
25 x 3 mm Green 0.01 kg CP035
25 x 3 mm Grey 0.01 kg CP040
25 x 3 mm Stone 0.01 kg CP045
25 x 3 mm White 0.01 kg CP050
* Not as illustrated (drawing available on request).
High grade Polypropylene, UV stabilized against degradation by sunlight
and non-brittle to prevent cold weather damage. Available in six colours to
match bare and PVC covered copper and aluminium tapes.
Fix using countersunk wood screws 11⁄
2” No. 10 or M6 (Part no.
SW005 or SW105) and wall plugs (Part no. PS305 ) - see Accessories
page 72.
Conductor
diameter
Colour Weight Part
each No.
For use with bare solid circular conductor
8 mm Brown 0.01 kg CP887
8 mm Grey 0.01 kg CP872
For use with PVC covered solid circular conductor
10 mm* Brown 0.01 kg CP886
10 mm* Black 0.01 kg CP861
10 mm* Grey 0.01 kg CP871
10 mm* Stone 0.01 kg CP876
10 mm* White 0.01 kg CP881
* PVC covered 8 mm conductor.
High grade Polypropylene, UV stabilized against degradation by sunlight and
non-brittle to prevent cold weather damage. Available in five colours to
match bare and PVC covered copper and aluminium solid circular conductors.
Non-metallic push-in clip
Non-metallic DC tape clip
CP020
CP872
