65 / 300
Conductor
size
Conductor
material
Weight
Part
each
No.
25 x 3 mm to 50 mm²
Copper
0.32 kg
CT125
25 x 3 mm to 70 mm²
Copper
0.30 kg
CT130
25 x 3 mm to 95 mm²
Copper
0.28 kg
CT135
Furse, Wilford Road, Nottingham, NG2 1EB • Tel: +44 (0)115 964 3700 • Email:
enquiry@furse.com• Web:
www.furse.comTSC-0912 - 09.10.12
Conductor network
Manufactured from high quality copper alloy. Simple to install, providing an
effective low resistance connection between overlapping stranded
conductors allowing cross, tee, through and right angle joints to be formed.
BS EN 50164-1 Class H
Tightening torque 6 Nm
Conductor
diameter
Conductor
material
Weight
Part
each
No.
50 mm
2
Copper
0.32 kg
CR810
70 mm
2
Copper
0.29 kg
CR815
95 mm
2
Copper
0.25 kg
CR820
Square clamp
CR815
Manufactured from high quality copper alloy. Simple to install, providing
an effective low resistance connection between conductor tape and
stranded copper conductor, allowing cross, tee, through and right angle
joints to be formed.
BS EN 50164-1 Class H
Fix using countersunk wood screws 1
1
⁄
2
” No. 10 or M6 (Part no.
SW005
) and wall plugs (Part no.
PS305
) - see Accessories page 72.
Tightening torque 5 Nm
Cable to tape square clamp
NEW
NEW
CT130
