Conductor network
Manufactured from high quality copper alloy. Simple to install, providing an
effective low resistance overlap connection between stranded copper cables.
BS EN 50164-1 Class H
Fix using countersunk wood screws 1
1
⁄
2
” No. 10 or M6 (Part no.
SW005
) and wall plugs (Part no.
PS305
) - see Accessories page 72.
Tightening torque 12 Nm
Test clamp
BS EN 50164-1 Class H
Tightening torque 12 Nm
Conductor
diameter
Conductor
size
Conductor
material
Weight
Part
each
No.
8 mm
25 x 3 mm
Copper
0.20 kg
CN305
8 mm
25 x 3 mm
Aluminium
0.09 kg
CN310
Designed to provide low resistance tee joints in solid circular conductor
networks. These multi-purpose clamps can produce circular to circular or
circular to tape connection in both through and tee configurations.
Manufactured from high quality copper and aluminium alloys for excellent
corrosion resistance.
Conductor
diameter
Conductor
material
Weight
Part
each
No.
50 mm
2
Copper
0.39 kg
CR855
70 mm
2
Copper
0.40 kg
CR860
95 mm
2
Copper
0.40 kg
CR865
Test clamp
CN305
CR860
