Conductor network
Maximum
conductor size
Conductor
material
Weight Part
each No.
26 x 12 mm Copper 0.62 kg CT405
Manufactured from a high quality copper alloy. Simple to install, providing
an effective low resistance connection between overlapping tapes. The
clamped connection is easily made/remade to allow for periodic testing.
Enables cross, tee, through and right angle joints to be formed.
BS EN 50164-1 Class H
Fix using countersunk wood screws 11⁄
2” No. 10 or M6 (Part no.
SW005) and wall plugs (Part no. PS305) - see Accessories page 72.
Tightening torque 15 Nm
Maximum
conductor size
Conductor
material
Weight Part
each No.
26 x 8 mm Copper 0.84 kg CT305
Manufactured from a high quality copper alloy. Simple to install, providing
an effective low resistance connection between overlapping tapes. The
clamped connection is easily made/remade to allow for periodic testing.
Enables cross, tee, through and right angle joints to be formed.
BS EN 50164-1 Class H
Fix using countersunk wood screws 11⁄
2” No. 10 or M6 (Part no.
SW005) and wall plugs (Part no. PS305) - see Accessories page 72.
Tightening torque 20 Nm
Screwdown test clamp
Plate type test clamp
CT405
CT305
