Conductor network
Designed to provide low resistance parallel joints in solid circular conductor
networks. Manufactured from high quality copper and aluminium alloys for
excellent corrosion resistance.
BS EN 50164-1 Class H
Tightening torque 12 Nm
Conductor
diameter
Conductor
material
Weight Part
each No.
8 mm Copper 0.17 kg CS405
8 mm Aluminium 0.08 kg CS410
Jointing clamp
Test/junction clamp
Conductor
size
Conductor
material
Weight Part
each No.
26 x 8 mm Copper 0.29 kg CN105-H†
26 x 8 mm Aluminium 0.12 kg CN005*
* Not as illustrated (drawing available on request).
BS EN 50164-1 Class H
†UL96 (CN105-H)
Tightening torque CN005 15 Nm; CN105-H 13 Nm
Manufactured from high quality copper and aluminium alloys. Simple to
install, providing an effective low resistance connection between
overlapping tapes. The clamped connection is easily made/remade to allow
for periodic testing.
CS405
CN105-H
