www.emergi-lite.co.ukcompact & explosion proof
Hazard-Lite
Explosion proof luminaire.
IP66 to IEC529 rated - explosion proof
and waterproof
Suitable for Zone 1 and Zone 2
2 x M20 - ISO (1 plugged) cable entry
Corrosion resistant light alloy body and end cap
with a polycarbonate overtube
4 wire and earth terminals with loop facility
(max. cable size 4 mm²)
Certification Code: EEx d IIC T6; Certification
Standard: EN50014-018; Certifying Authority:
SIRA, ATEX
Manufactured in the UK
Dimensions
Ø140
448
Order
Code
Input
Voltage
Lamp
Type
Lamp
Output
Operation /
Duration (hrs)
Recharge
Period
Environment
Weight
XP2312
220 - 240 Vac, 50/60 Hz
8 W T5
100 lumens
NM3
24 hours
0 - 40 °C
5.5 kg
XP4322
220 - 240 Vac, 50/60 Hz
8 W T5
100 lumens
CNM3
24 hours
0 - 40 °C
5.5 kg
Luminaire
Zone Classification
Zone 0 >
An explosive gas-air mixture exists continuously, or
for long periods.
Zone 1 >
An explosive gas-air mixture is likely in normal
circumstances.
Zone 2 >
An explosive gas-air mixture is not likely to occur in
normal operation and then only for a short time.
Code of Practice
BS 5345, the UK Standard for hazardous area
equipment, installation and maintenance gives
guidance relating to:
1 >
The degree of protection suitable for the
hazardous zone
2 >
The gas groups of any gases or vapours
3 >
The temperature classification of the gases
or vapours
Information summary for guidance only
For detailed information on hazardous area requirements please consult the British Standard code, BS 5345.
For further information on this product, or for discussion of hazardous area
lighting using the Hazard-Lite or DTS product range of explosion proof
luminaires, contact Emergi-Lite.
EEx d IIC T6 flameproof luminaire, to Gas Group IIC (hydrogen), capable of
withstanding a maximum temperature of 85°C
