Range-Lite robust & high output
Order
Code
Input
Voltage
Lamp
Type
Power
Consumption
Lamp
Output*
Operation /
Duration (hrs)
Recharge
Period
Environment Weight
HL551 220 - 240 Vac, 50/60 Hz 2 x 55 W TH 100 mA 1800 lumens NM1 24 hours 0 - 25 °C 7.8 kg
HL551PC 220 - 240 Vac, 50/60 Hz 2 x 55 W TH 100 mA 1800 lumens NM1 24 hours 0 - 25 °C 7.8 kg
HL1553 220 - 240 Vac, 50/60 Hz 1 x 55 W TH 100 mA 900 lumens NM3 24 hours 0 - 25 °C 7.8 kg
For AC/AC or AC/DC slave units please refer to our EMEX Central Power Supply Systems Catalogue. HL551PC includes polycarbonate lenses.
* Total lamp output for all lamps on unit.
Twin beam unit
Dimensions
200
120
177
470
135
90
343
74
Accessories
Order Code Description
HLWG Protective wire guard
For Range-Lite spacing data, please contact Emergi-Lite.
For accessory drawings, see page 93.
For further information on Naveo and IR2 emergency luminaire testing
formats, see pages 73 - 77 or contact Emergi-Lite.
Options
Order Code Description
Suffix TD Run on timer
Cable entry via 20 mm
knockouts on rear and
sides of unit.
Twin beam emergency lighting.
Ideal for indoor use in larger warehouses, factory
spaces and industrial open areas
Can be mounted upright on a wall or stanchion
55 Watt tungsten halogen lamps
Mild steel enclosure
Single lamp option available
Optional time delay feature to support slow start
mains luminaires
Designed & manufactured to meet the
requirements of BS EN 60598.2.22
Manufactured in Hungary
