robust & high output Range-Lite
67
Thomas & Betts Ltd., Emergi-Lite, Bruntcliffe Lane, Morley, Leeds, LS27 9LL • Tel: +44 (0)113 281 0600 •
Email: • Web:
Twin beam emergency lighting.
Ideal for indoor use in smaller warehouses, factory
spaces and industrial open areas
Can be mounted upright on a wall or stanchion
20 Watt tungsten halogen lamps with
polycarbonate lenses
Mild steel enclosure with white powder coat
Optional battery retaining clamp, or time
delay feature
Designed & manufactured to meet the
requirements of BS EN 60598.2.22
Manufactured in Hungary
Order
Code
Input
Voltage
Lamp
Type
Power
Consumption
Lamp
Output*
Operation /
Duration (hrs)
Recharge
Period
Environment Weight
HV203 220 - 240 Vac, 50/60 Hz 2 x 20 W TH 100 mA 600 lumens NM3 24 hours 0 - 25 °C 7.8 kg
For AC/AC or AC/DC slave units please refer to our EMEX Central Power Supply Systems Catalogue.
* Total lamp output for all lamps on unit.
Twin beam unit
Dimensions
214
99
358
Ø 120
260
61.5
Accessories
Order Code Description
HVBC Battery retaining clamp
HLWG Protective wire guard
For Range-Lite spacing data, please contact Emergi-Lite.
For accessory drawings, see page 93.
For further information on Naveo and IR2 emergency luminaire testing
formats, see pages 73 - 77 or contact Emergi-Lite.
Options
Order Code Description
Suffix TD Run on timer (20 W version only) to support slow start mains luminaires
Cable entry via 20 mm
knockouts on rear and
sides of unit.
