www.emergi-lite.co.ukrobust & high output
Range-Lite
Twin beam emergency lighting.
Rated for external use with battery and electronics
enclosure sealed to IP65
Remote mounting lamps with horizontal and
vertical head adjustment
Polycarbonate enclosure with screw locked
front panel
Meets the anti-glare requirement when projectors
mounted at least 30° above the line of sight
Optional time delay feature to support slow start
mains luminaires
Designed & manufactured to meet the
requirements of BS EN 60598.2.22
Manufactured in Hungary
Order
Code
Input
Voltage
Lamp
Type
Power
Consumption
Lamp
Output*
Operation /
Duration (hrs)
Recharge
Period
Environment
Weight
HL203E3
220 - 240 Vac, 50/60 Hz 2 x 20 W TH 100 mA
600 lumens
NM3
24 hours
0 - 25 °C
7.6 kg
HL551E3
220 - 240 Vac, 50/60 Hz 2 x 55 W TH 100 mA 1800 lumens
NM1
24 hours
0 - 25 °C
7.6 kg
For AC/AC or AC/DC slave units please refer to our EMEX Central Power Supply Systems Catalogue.
* Total lamp output for all lamps on unit.
Twin beam unit
Dimensions
130
254
254
280
280
For Range-Lite spacing data, please contact Emergi-Lite.
For further information on Naveo and IR2 emergency luminaire testing
formats, see pages 73 - 77 or contact Emergi-Lite.
Options
Order Code Description
Suffix TD
Run on timer
Cable entry via 20 mm
knockouts on rear and
sides of unit.
74
177
90
141
101
85
