Naveo Testing Solutions
When do you need to test?
Fire Safety Regulations require emergency lighting to
be tested in accordance with BS 5266-8 (EN 50172).
Simplified Testing Regime
Daily check central power supply indicators for
healthy operation
Monthly functional check
Yearly duration check
Always keep documented records
Automatic test devices should meet IEC 62034
What needs to be checked & tested?
Mains present and healthy
Battery present
Battery charging
Inverter circuit in emergency operation
Lamp functions and in circuit
Duration
Effective testing with Naveo
Naveo’s comprehensive, technologically advanced
approach ensures testing to meet the requirements
of BS 5266-8 (EN 50172):
Naveo tests can be run either manually or
automatically
Unattended tests can be performed using the
schedule program
All automatic test schedules can be easily
programmed for the type of test required and
for the time the test is to be performed
All results of tests are stored at the remote server
for recall at a later date
Each luminaire is programmed with an address
which is used for interrogation and fault diagnosis
Supporting Naveo installations
Naveo is fully supported through our project sales and
technical teams, including:
Design of the emergency lighting system with
Naveo compatible emergency luminaires
Practical advice on installation matters, such as
power and data cable structure, system set-up etc
Full commissioning of the system, pre-operation,
from our highly experienced field service team
Maintenance contracts, available as required to
support the installation, for added peace of mind
Project after-sales support, with project files
retained by our service department so that
preparation of additional luminaires as required
is a straightforward task
Technical literature & advice
Please contact a member of our sales team for full
details and advice on Naveo, including:
Technical design guide, providing in-depth
technical information on the system
System demonstrations, arranged at your own
premises or at our head office for an informed
assessment of the system and software capabilities
Additionally, a separate brochure explaining the Naveo
solution in full is available on request.
Inspection & maintenance
8
Emergi-Lite,Bruntcliffe Lane,Morley, Leeds, LS27 9LL • Tel: +44 (0)113 281 0600
In real-time over the
internet
Withoptimum safety and
control inmind, access the site
via naveosystem.co.uk to
monitor, review or set
parameters for testing, alerting
ormaintenance planning.
2
1
3
5
4
1 |Bus communication cable
2 |DataCollection Panel (DCP)
3 |Internet connection
4 |Naveo external serverwith all
DCP information
5 |PC, laptop or smartphone
When on-site during a
maintenance and inspection visit
Locally,when theDCPhub isnot connected to the
internet, it ispossible to run local tests from a
portable computer device (laptop, tablet for example).
Make a visual inspection and record theobservations
manually.
Observed data can be inputted to the system later.
Carryout any remedialmaintenance according to
pre-planningwith the spares advisedon theprevious
materials (spares to take) list.
Non-addressed general luminaires
or other items
During a site visit it is possible to record information
for items that arenotpartof the automatic test
schedule or addressed directly byNaveo. For example,
itmightbeuseful tonote the conditionof the fire
extinguishers in the log,orofother standard
emergency lighting.
On return tobase the information canbeuploaded to
Naveo toupdate the information for such equipment.
Inspection & maintenance
9
User packages
Naveo is ideal for those carryingout inspections andmaintenance on self-contained emergency lighting
luminaires. It provides userswith a customised solution: (irrespective of the site size orbuilding
location) the system can be completely scaled to your requirements.
Always a suitable solution
Naveo comes in conveniently arrangedpricing
packages. The scopeof thepackagedependson the
current situation andgrowthpotential.Naveo allows
flexibility, sousers canbuildon the selections as time
goes by.
Observer Package
In this case, the client has an online overview of the
system status,while the installerhas access to all the
inspection andmaintenance functions.
SiteManager Packages
The SiteManagerpackage allows access to all sections
as illustrated above. The level to choosedependson
the extentof the installation and thenumber of
luminairesbeingmanaged.
Emergi-Lite,Bruntcliffe Lane,Morley, Leeds, LS27 9LL • Tel: +44 (0)113 281 0600
+ EXTRA100
100 additional luminaires
+ EXTRA500
500 additional luminaires
+ EXTRA1.000
1.000 additional luminaires
SITEMANAGER
100
SITEMANAGER500
SITEMANAGER1.000
SITEMANAGER
5.000
SITEMANAGER10.000
SETUP
PROGRAMMING
COMMISSIONING
Programming
Commissioning
Inspection
Status report
Preventative alerts
Visual inspection
Inspection log
Shopping list
Maintenance
Maintenance sheet
Certificate
1 SETUP 2 SIZE
PROGRAM +NUMBEROF LUMINAIRES 3 EXTENSION
EXTRA LUMINAIRES
did you know?
UseNaveo for a single-site
complex, or formultiple
locations across a town, city,
region or country.
As yourbusinessgrows, you
simply entermore buildings
into theNaveo sitemanager.
Emergency lighting
maintenance at
your fingertips
