Camarque decorative & low profile
Dimensions
Aesthetically pleasing, decorative luminaire.
28 Watt 2D high power luminaire
Fire-resistant polycarbonate luminaire body with
opal diffuser
Angled and banded trim options in a range
of finishes
Semi-recessing accessory available
Designed and manufactured to meet the
requirements of BS EN 60598.2.22
Manufactured in Hungary
Ceiling cutout 330 mm when semi-recessing.
For Camarque spacing data, see page 89.
For further information on Naveo, IR2 and Self-Test emergency luminaire
testing formats, see pages 73 - 78 or contact Emergi-Lite.
350
31
87
324
Order
Code
Input
Voltage
Lamp
Type
Power Cons.
Mains/
Self-contained
Lamp Output
Mains/
Self-contained
Operation /
Duration (hrs)
Recharge
Period
Environment Weight
CLQ28NM 220 - 240 Vac, 50/60 Hz 28 W 2D 200 / 250 mA 1800 / 250 lumens NM3 24 hours 0 - 25 ºC 2.6 kg
CLQ28M 220 - 240 Vac, 50/60 Hz 28 W 2D 200 / 250 mA 1800 / 250 lumens M3 24 hours 0 - 25 ºC 3.2 kg
CLQ28PHF 220 - 240 Vac, 50/60 Hz 28 W 2D 200 / - mA 1800 / 250 lumens 230 V - 0 - 25 ºC 2.1 kg
For AC/AC or AC/DC slave luminaires please refer to our EMEX Central Power Supply Systems Catalogue.
Luminaire
Cable entry via
20 mm hole on
rear of unit.
28 W only
Accessories
Order Code Description
CLQ/SR Semi-recessing kit
