J-LED
Recessed LED light source.
Ideal for general use in offices, public buildings,
retail and light industrial units
Polycarbonate enclosure finished in white
Versions for escape route (Suffix E) or open area
(Suffix A) use available
Single point high performance LED
Battery and control pack slot through a 39 mm
ceiling cut-out
Plug and socket supplied for mains connection
Designed & manufactured to meet the
requirements of BS EN 60598.2.22
Manufactured in the UK
Order
Code
Input
Voltage
Lamp
Type
Power
Consumption
Lamp
Output
Operation /
Duration (hrs)
Recharge
Period
Environment
Weight
LR2L1E
220 - 240 Vac, 50/60 Hz 1 x 1 W LED 10 mA
110 lumens
NM3
24 hours
0 - 25 °C
0.6 kg
LR2L1A
220 - 240 Vac, 50/60 Hz 1 x 1 W LED 10 mA
110 lumens
NM3
24 hours
0 - 25 °C
0.6 kg
LR3L1E
220 - 240 Vac, 50/60 Hz 1 x 1 W LED 28 mA
110 lumens
M3
24 hours
0 - 25 °C
0.6 kg
LR3L1A
220 - 240 Vac, 50/60 Hz 1 x 1 W LED 28 mA
110 lumens
M3
24 hours
0 - 25 °C
0.6 kg
* Recessed unit only. Weight of battery and control pack 0.8 kg.
Single point LED
Dimensions
Ø 36 mm
Ø 26
130
87
34.5
Ceiling hole Ø 38
12.6
70
80
For spacing data, please contact Emergi-Lite.
Ceiling cutout
39 mm diameter.
