Weatherforce practical & durable
58
Standard, surface mounted luminaire.
Simple, vandal resistant design suitable for general
use in interior and exterior locations
Available with high grade polycarbonate (B) or
cast aluminium (WA) enclosure
Opal diffuser as standard with clear polycarbonate
diffuser option available
Converts easily to exit sign with addition of
self-adhesive legend
Designed & manufactured to meet the
requirements of BS EN 60598.2.22
Manufactured in the UK (LED), and Hungary (FL)
Order luminaire and legend separately
Order
Code
Input
Voltage
Lamp
Type
Power
Consumption
Lamp
Output
Operation /
Duration (hrs)
Recharge
Period
Environment Weight
B2LS1 220 - 240 Vac, 50/60 Hz 1 W LED strip 12 mA 90 lumens NM3 24 hours 0 - 25 °C 1.7 kg
B3LS1 220 - 240 Vac, 50/60 Hz 1 W LED strip 27 mA 90 lumens M3 24 hours 0 - 25 °C 2.1 kg
B2311 220 - 240 Vac, 50/60 Hz 8 W T5 30 mA 170 lumens NM3 24 hours 0 - 25 °C 1.7 kg
B3311 220 - 240 Vac, 50/60 Hz 8 W T5 60 mA 170 lumens M3 24 hours 0 - 25 °C 1.9 kg
B4321 220 - 240 Vac, 50/60 Hz 2 x 8 W T5 60 mA 170 lumens CNM3 24 hours 0 - 25 °C 2.0 kg
WA2321 220 - 240 Vac, 50/60 Hz 2 x 8 W T5 60 mA 250 lumens NM3 24 hours 0 - 25 °C 2.1 kg
Fluorescent = NiCaD, LED = NiMH. For AC/AC or AC/DC slave units please refer to our EMEX Central Power Supply Systems Catalogue.
Luminaire
Legends
RSE2120 RSE3120 RSE6120 RSE5120 RSE120
Legends are self-adhesive label. Euro pictogram legends shown. ISO 7010 format legends are available to order, see page 95 or contact Emergi-Lite.
Options
Order Code Description
Suffix 1 Clear prismatic diffuser
Dimensions
140
400
100
Accessories
Order Code Description
BBZ Semi-recessing bezel in white
VRKIT Vandal resisting security screw kit
BWG Protective wire guard
For Weatherforce spacing data, see page 88.
For accessory drawing, see page 93.
For further information on Naveo, IR2 and Self-Test emergency luminaire
testing formats, see pages 73 - 78 or contact Emergi-Lite.
Ceiling cutout
390 x 130 mm
when semi-recessing.
Cable entry via BESA on rear
and 20 mm drill holes on
ends of unit.
(Testing & Kitemark - fluorescent lamps only)
