practical & durable Day-Lite Ex-cel
59
Thomas & Betts Ltd., Emergi-Lite, Bruntcliffe Lane, Morley, Leeds, LS27 9LL • Tel: +44 (0)113 281 0600 •
Email: • Web:
Standard, surface mounted luminaire.
Simple, vandal resistant design suitable for general
use in interior and exterior locations
High grade polycarbonate enclosure
Converts easily to exit sign with addition of
self-adhesive legend
Designed & manufactured to meet the
requirements of BS EN 60598.2.22
Manufactured in the UK (LED), and Hungary (FL)
Order luminaire and legend separately
Order
Code
Input
Voltage
Lamp
Type
Power
Consumption
Lamp
Output
Operation /
Duration (hrs)
Recharge
Period
Environment Weight
XW2LS11 220 - 240 Vac, 50/60 Hz 1 W LED strip 12 mA 90 lumens NM3 24 hours 0 - 25 °C 1.1 kg
XW3LS11 220 - 240 Vac, 50/60 Hz 1 W LED strip 27 mA 90 lumens M3 24 hours 0 - 25 °C 1.3 kg
XXW23111 220 - 240 Vac, 50/60 Hz 8 W T5 30 mA 170 lumens NM3 24 hours 0 - 25 °C 1.2 kg
XXW33111 220 - 240 Vac, 50/60 Hz 8 W T5 60 mA 170 lumens M3 24 hours 0 - 25 °C 1.5 kg
Fluorescent = NiCaD, LED = NiMH. For AC/AC or AC/DC slave units please refer to our EMEX Central Power Supply Systems Catalogue.
Luminaire
Legends
RSE2X RSE3X RSE6X RSE5X
Legends are self-adhesive label. Euro pictogram legends shown. ISO 7010 format legends are available to order, see page 95 or contact Emergi-Lite.
Dimensions
98
343
73
Accessories
Order Code Description
XTR Semi-recessing bezel in white
See Silver-Scape (page 55) for recessed version.
For Day-Lite Ex-cel spacing data, see page 89.
For accessory drawing, see page 93.
For further information on IR2 and Self-Test emergency luminaire testing
formats, see pages 76 - 78 or contact Emergi-Lite.
Cable entry via BESA on rear
and 20 mm drill holes on
rear and ends of unit.
Ceiling cutout 342 x 95 mm when semi-recessing.
(Testing & Kitemark - fluorescent lamps only)
