Silver-Scape basic & functional
54
Thomas & Betts Ltd., Emergi-Lite, Bruntcliffe Lane, Morley, Leeds, LS27 9LL • Tel: +44 (0)113 281 0600 •
Email: • Web:
Recessed emergency exit sign.
Suitable for application in suspended ceilings
Polycarbonate enclosure with wing fixings for
recessed application
Diffuser panel with slot for exit sign legend
Designed & manufactured to meet the
requirements of BS EN 60598.2.22
Manufactured in the UK (LED), and Hungary (FL)
Order recessed unit, diffuser panel and
legend separately
Dimensions
For further information on IR2 and Self-Test emergency luminaire testing
formats, see pages 76 - 78 or contact Emergi-Lite.
34
407
165
174
317
Order
Code
Input
Voltage
Lamp
Type
Power
Consumption
Operation /
Duration (hrs)
Recharge
Period
Environment Weight*
RB3LS1 220 - 240 Vac, 50/60 Hz 1 W LED strip 27 mA M3 24 hours 0 - 25 °C 1.3 kg
RB3311 220 - 240 Vac, 50/60 Hz 8 W T5 60 mA M3 24 hours 0 - 25 °C 1.3 kg
* Without legend. Fluorescent = NiCaD, LED = NiMH. For AC/AC or AC/DC slave units please refer to our EMEX Central Power Supply Systems Catalogue.
Recessed unit
Diffuser panel
Order Code Description
RE00 Recessed diffuser panel with sign panel slot
Ceiling cutout 380 x 136 mm.
Cable entry via
20 mm knockouts
on rear of unit.
Legends
Single
sided
Double
sided
XE02A31 XE03A31 XE06A31 XE05A31 XE03/6A32 XE02/2A32
Legends are screen printed and slot through the metal trim plate. Euro pictogram legends shown. ISO 7010 format legends are available to order, see page 95 or
contact Emergi-Lite.
(Testing & Kitemark - fluorescent lamps only)
