contemporary & stylish Silver-Lite
49
Thomas & Betts Ltd., Emergi-Lite, Bruntcliffe Lane, Morley, Leeds, LS27 9LL • Tel: +44 (0)113 281 0600 •
Email: • Web:
Recessed luminaire.
Ideal for modern commercial environments
Available with stainless steel, brushed silver
aluminium, white or mirror finish brass trim plate
Heavy duty steel enclosure with wing fixings for
recessed application
Separate metal trim plate with
light-optimised diffuser
Designed & manufactured to meet the
requirements of BS EN 60598.2.22
Manufactured in the UK (LED), and Hungary (FL)
Order recessed unit and trim plate separately
Order
Code
Input
Voltage
Lamp
Type
Power
Consumption
Lamp
Output
Operation /
Duration (hrs)
Recharge
Period
Environment Weight
AR2LS 220 - 240 Vac, 50/60 Hz 1 W LED strip 12 mA 90 lumens NM3 24 hours 0 - 25 °C 1.8 kg
AR3LS 220 - 240 Vac, 50/60 Hz 1 W LED strip 27 mA 90 lumens M3 24 hours 0 - 25 °C 2.0 kg
ARV23 220 - 240 Vac, 50/60 Hz 8 W T5 30 mA 100 lumens NM3 24 hours 0 - 25 °C 1.8 kg
ARV33 220 - 240 Vac, 50/60 Hz 8 W T5 60 mA 100 lumens M3 24 hours 0 - 25 °C 2.0 kg
Fluorescent = NiCaD, LED = NiMH. For AC/AC or AC/DC slave units please refer to our EMEX Central Power Supply Systems Catalogue.
Recessed unit
Trim plate
Order Code Description
AR011 White trim
AR041 Brass trim
AR051 Stainless steel trim
AR061 Aluminium trim
Dimensions
For Silver-Lite spacing data, see page 87.
For further information on Naveo, IR2 and Self-Test emergency luminaire
testing formats, see pages 73 - 78 or contact Emergi-Lite.
75
361
169
Ceiling cutout 325 x 140 mm.
Cable entry via
20 mm knockouts
on rear and ends
of unit.
(Testing & Kitemark - fluorescent lamps only)
