Silver-Lite contemporary & stylish
48
Thomas & Betts Ltd., Emergi-Lite, Bruntcliffe Lane, Morley, Leeds, LS27 9LL • Tel: +44 (0)113 281 0600 •
Email: • Web:
Recessed exit sign.
Ideal for modern commercial environments
Available with stainless steel, brushed silver
aluminium, white or mirror finish brass trim plate
Heavy duty steel enclosure with wing fixings for
recessed application with separate slotted metal
trim plate to support legend
Designed & manufactured to meet the
requirements of BS EN 60598.2.22
Manufactured in the UK (LED), and Hungary (FL)
Order recessed unit, trim plate and
legend separately
Order
Code
Input
Voltage
Lamp
Type
Power
Consumption
Operation /
Duration (hrs)
Recharge
Period
Environment Weight
AR3LS 220 - 240 Vac, 50/60 Hz 1 W LED strip 27 mA M3 24 hours 0 - 25 °C 2.0 kg
ARV33 220 - 240 Vac, 50/60 Hz 8 W T5 60 mA M3 24 hours 0 - 25 °C 2.0 kg
Fluorescent = NiCaD, LED = NiMH. For AC/AC or AC/DC slave units please refer to our EMEX Central Power Supply Systems Catalogue. Silver-Lite exit sign available
with slim profile trim plate, to special order. Please contact Emergi-Lite for details.
Trim plate
Legends
Single
sided
Double
sided
XE02A31 XE03A31 XE06A31 XE05A31 XE03/6A32 XE02/2A32
Legends are screen printed and slot through the metal trim plate. Euro pictogram legends shown. ISO 7010 format legends are available to order, see page 95 or
contact Emergi-Lite.
Dimensions
For further information on Naveo, IR2 and Self-Test emergency luminaire
testing formats, see pages 73 - 78 or contact Emergi-Lite.
170
75
169
363
137
324
320
9
Order Code Description
AE01 White slotted trim plate
AE04 Brass slotted trim plate
AE05 Stainless steel slotted trim plate
AE06 Brushed aluminium slotted trim plate
Recessed unit
Ceiling cutout
325 x 140 mm.
Cable entry via
20 mm knockouts
on rear and ends
of unit.
(Testing & Kitemark - fluorescent lamp only)
