Maximum distances for remote location
The maximum permitted distances from the processor in any one remote system are
shown in the table below:
Type of I
/
O modules
Reference
Length of bus X
remote system
5
Discrete inputs
(1)
TSX DEY
ppp
250
m
Discrete Outputs
TSX DSY
ppp
Preventa safety module
TSX PAY 262
Analog I/O
(2)
TSX AEY
ppp
/
ASY
ppp
175
m less than the
length
3
of bus X
Counter/motion control
modules
(3)
TSX CTY
p
A/CAY21/CAY41/CFY
p
1
Weighing modules
TSX ISP Y101/Y121
AS-Interface Bus modules
TSX SAY 1000
Remote location of
bus X not permitted
SERCOS motion module
TSX CSY 84/85/164
Communication modules
TSX SCY 21601/11601
Ethernet Modbus/TCP modules TSX ETY 110WS/4103/5103/WMY 100
Fieldbus modules
TSX IBY 100/PBY100
Discrete I/O
TSX DMY 28FK/28RFK
225
m less than the
length
3
of bus X
(1)
Discrete inputs
TSX DEY 16FK (version
06)
(2)
Analog I/O
TSX AEY 810/1614
TSX ASY 410 (version
11)
(3)
Counter/motion control
modules
TSX CTY 2C/CCY 1128
TSX CAY 22/42/33
Description
The front panel of the bus X remote rackmaster module
TSX REY 200
comprises:
1
A display block with 6 indicator lamps:
v
RUN indicator: module running
v
ERR indicator: module has an internal fault
v
I/O indicator (red): module has an external fault
v
MST indicator module acting as master or slave
v
CH0 indicator: channel 0 operating
v
CH1 indicator: channel 1 operating
2
A 5-way SUB-D 9 connector for the connection of channel 0
3
A 5-way SUB-D 9 connector for the connection of channel 1
References
Description
Item no.
Operation
Description
Reference
Weight
kg
Extendable racks
–
4/6/8/12
positions See page 2/10
Bus X remote
rackmaster module
1
or
4
Master/slave
2
channels
TSX REY 200
–
Connection cables and accessories
(
see also page 2/10)
Description
Item no.
Use
Length
Reference
Weight
kg
Bus X cables
supplied on a drum
5
Connection of two TSX
REY 200 modules
Class C1 flame
resistance
250
m
TSX CBRY 2500
–
Cable for daisy chain
mounting
(1)
250
m
TSX CBRY 2500F
–
5-
ways SUB-D 9
connectors
For ends of cables TSX
CBRY 2500
p
Sold in lots of 5
TSX CBRY K5
–
Description
Item no.
Use
Composition Reference
Weight
kg
Line terminators
6
Must be fitted on each
TSX RKY
p
EX end rack
2
x 9-way SUB-D
connectors
Sold in lots of 2
TSX TLY EX
0.050
(1)
Mobile installations: cables as per VDE 472, part 603/H: (60 000 operations max.):
-
For use on cable drag chain: minimum bend radius of 75 mm
-
For use on gantry crane, subject to compliance with certain installation conditions
(
acceleration, speed, length etc.): please consult our Customer Care Centre.
-
Not authorized for use on robots, or multi-axis applications.
Description,
references
Modicon Premium automation
platform
Multirack configuration with remote module
TSX REY 200
TSX TLY EX
1
2
3
