Accessories
Description
Use
Composition
Reference
Weight
kg
Bus X
connectors
For TSX CBY 1000
cable ends
2
x 9-way SUB-D connectors
TSX CBY K9
0.080
Bus X electrical
transient
suppressors
For bus X daisy
chain cable
lengths > 28 m
2
transient suppressors
with 9-way SUB-D connectors
TSX TVSY 100
0.200
Line terminators
Compulsory on the
2
TSX RKY
p
EX
end racks
2
x 9-way SUB-D connectors
marked A and B
TSX TLY EX
0.050
Protective covers
Unoccupied
position on racks
TSX RKY
p
or
TSX RKY
p
EX
5
screw-on covers
TSX RKA 02
0.050
Connector
installation kit
Fitting TSX CBY
K9 connectors
2
crimping pliers, 1 pen
(1)
TSX CBYACC 10
–
Fixing screws
M6 x 25
Mounting of racks
TSX RKY
p
or
TSX RKY
p
EX
50
screws with captive washer
and hexagonal slotted head
TSX ACC VA625
0.350
(1)
Installation of connectors on the cable also requires a wire stripper, a pair of scissors and a digital ohmmeter.
Modicon Premium automation
platform
Multirack configuration without remote module
Accessories
References
(
continued)
TSX TLY EX
TSX TVSY 100
Presentation:
page 2/8
Description:
page 2/9
