38 / 413
2/10
References
Extendable racks
Description
Type of module to be installed
Capacity
Reference
Weight
kg
Extendable racks
for multirack
configuration
(16
racks max.)
(1)
TSX PSY power supply,
TSX P57 or TSX H57 processor
(
main rack 0),
I/O modules
application-specific modules and
communication modules
4
positions
TSX RKY 4EX
1.160
6
positions
TSX RKY 6EX
1.500
8
positions
TSX RKY 8EX
1.780
12
positions
TSX RKY 12EX
2.340
Connection cables
Description
Use
Composition
Length
Reference
Weight
kg
Bus X
daisy chain cables
(
total length 100 m
max.)
(2)
Between
TSX RKY
p
EX
racks
2
x 9-way SUB-D
connectors
1
m
TSX CBY 010K
0.160
3
m
TSX CBY 030K
0.260
5
m
TSX CBY 050K
0.360
12
m
TSX CBY 120K
1.260
18
m
TSX CBY 180K
1.860
28
m
TSX CBY 280KT
(3)
2.860
38
m
TSX CBY 380KT
(3)
3.860
50
m
TSX CBY 500KT
(3)
5.060
72
m
TSX CBY 720KT
(3)
7.260
100
m
TSX CBY 1000KT
(3)
10.060
Cable on reel
Length to be
fitted with
TSX CBY K9
connectors.
Cable with free ends,
2
line testers
100
m
TSX CBY 1000
12.320
(1) 16
TSX RKY 4EX/6EX/8EX
racks max. (4, 6 or 8 slots) or 8
TSX RKY 12EX
racks max. (12 slots).
Using the 12 -slot rack is the same as occupying two racks with 4, 6 or 8-slots.
(2)
Up to 2 x 350 m when using bus X remote module
TSX REY 200
(
see page 2/12).
(3)
Cable supplied with a set of 2
TSX TVSY 100
electrical transient suppressors.
Modicon Premium automation
platform
Multirack configuration without remote module
Extendable racks and connection cables
Presentation:
page 2/8
Description:
page 2/9
TSX RKY 6EX
