References
Each
TSX RKY
p
and
TSX RKY
p
EX
rack must be equipped with a single or
double-format power supply module (slot marked PS).
The power required to supply each TSX RKY rack depends on the type and number
of modules installed in the rack. It is therefore necessary to draw up a power
consumption table rack by rack in order to determine which TSX PSY power supply
module is the most suitable for each rack (see page 9/6).
Power supply modules
Power
supply
Available power
(1)
Format Reference
(2)
Weight
kg
5
V
c
24
VR
c
24
VC
c
Total
24
V
c
non-isolated
(3)
15
W
15
W –
30
W Standard
TSX PSY 1610M
0.540
35
W 19 W –
50
W Double
TSX PSY 3610M
0.780
24...48
V
c
isolated
35
W 19 W –
50
W Double
TSX PSY 5520M
0.890
100...240
V
a
25
W 15 W 12 W 26 W Standard
TSX PSY 2600M
0.510
00...120
V
a
200...240
V
a
35
W 19 W 19 W 50 W Double
TSX PSY 5500M
0.620
75
W –
38
W
(
SELV)
77
W Double
TSX PSY 8500M
0.740
Accessories
Description Use
Sold in
lots of
Reference
Weight
kg
Batteries
Internal RAM memory backup
on TSX P57 processors
(
to be fitted in the power supply module)
1
TSX PLP 01
0.010
10
TSX PLP 101
0.100
(1)
Voltages 5 V
c
and 24 VR
c
for power supply to Premium PLC modules, voltage 24 VC
c
for power supply to input sensors. The sum of power consumed on each voltage (5 V
c
,
24
VR
c
and 24 VC
c
)
must not exceed the total power of the module. See power
consumption table on page 9/6.
(2)
Product supplied with a processor RAM memory backup battery.
(3)
The internal 0 V of the module is connected to the PLC earth.
References
TSX PSY 5500M
Description:
page 2/2
Functions:
page 2/3
