References
(
continued)
PL7 Micro/Pro software licences
Description
For PLCs
Licence type
Reference
Weight
kg
PL7 Micro Open Team
software licence
TSX Micro
Team (10 stations)
(1)
TLX OT PL7M P45M
–
PL7 Pro Open Team
software licence
TSX Micro, Premium
Team (10 stations)
(1)
TLX OT PL7P P45M
–
PL7 Pro Open Site
software licence
TSX Micro, Premium
Site (>10 stations)
(1)
TLX OS PL7P P45M
–
Separate parts
Description
Description
Reference
Weight
kg
X-Way drivers package
for compatible PC
CD-ROM including X-Way drivers (see page 6/41)
Includes multilingual user documentation
TLX CD DRV20M
–
Description
Use
Processor port
To PC port
Length Reference
Weight
kg
Compatible PC
connection cables
Mini-DIN port
TSX Micro/Premium
RS 232D
(
SUB-D 15-way
connector)
2.5
m
TSX PCX 1031
0.170
USB port (USB/
RS 485
converter)
0.4
m
TSX CUSB 485
(2)
0.144
USB port
(
mini-DIN/RJ45
cable)
2.5
m
TSX CRJMD 25
(2)
0.150
Description
Use
Reference
Weight
kg
Universal Bluetooth
®
Interface (UBI)
Provides Bluetooth
®
connectivity for products such as
the Modicon M340/Premium platforms and Altivar/Lexium
servo drives, via their serial port (RS 485).
Used for setting up and maintenance of products.
Designed for permanent installation and can be safely fitted
on the inside or outside of electrical enclosures.
b
Protocols supported: Modbus and Uni-Telway
b
Powered via the product’s RS 485 serial port
b
Max. range in direct line of sight: 20 m
The kit comprises:
b
AUniversal Bluetooth
®
interface (UBI)
b
An RJ45/mini-DIN cable (length 1 m)
b
An RJ45/RJ45 cable (length 1 m)
b
A fixing clamp for installation inside the electrical enclosure
b
ACD with configuration software and user manual
TCS WAAC 13FB
0.320
(1)
Team user workstations located on the same site.
(2)
The
TSX CUSB 485
converter requires the use of the
TSX CRJMD 25
cordset (equipped with 2 connectors, 1 x mini-DIN
and 1 x RJ45).
TSX PCX 1031
TSX CUSB 485
References
(
continued)
