PL7 software
PL7 Micro/Junior/Pro
References
PL7 Micro/Junior/Pro are multi-language (English, French, German, Italian and Spanish) software packages
designed for PC compatibles
(1)
with Windows 2000, XP, Vista or 7 (all 32-bit) operating system.
b
For a station, the package comprises:
v
1
CD-ROM containing the multilingual PL7 software, PL7 demonstration applications and the Uni-Telway
terminal link driver
v
2
CD-ROMs containing multilingual technical documentation
v
1
CD-ROM containing Service Pack 5
b
For 3-station packages, the quantities above are tripled.
Note
:
The operating systems of Modicon TSXMicro/Premium platforms are available on our website
www.schneider-electric.com.Cables for connection to the PC are to be ordered separately and depend on the desired number of users and
the type of link (RS 232 or USB port). See separate parts (page 6/43).
PL7 Micro software packages
PL7 Micro software enables programming in Instruction List, Ladder Diagram, Structured Text and Grafcet
languages.
It also enables the setting up of application-specific functions, maintenance and diagnostics of the developed
applications. It includes the PL7 2 application converter.
Description
For PLCs
Licence type
Reference
Weight
kg
PL7 Micro
software packages
TSX Micro
Single (1 station)
TLX CD PL7M P45
–
Group (3 stations)
TLX CD3 PL7M P45
–
PL7 Micro and SyCon V2.10
software packages
TSX Micro
Single (1 station)
TLX CD PL7M PC45
–
Software update for earlier
version PL7 Micro software
TSX Micro
Single (1 station)
TLX RCD PL7M P45M
–
Group (3 stations)
TLX RCD3 PL7M P45M
–
Software update for earlier
version PL7 Micro software
Supplied with SyCon V2.10
TSX Micro
Single (1 station)
TLX RCD PL7M PC45M
–
PL7 Junior software packages
PL7 Junior software enables programming in Instruction List, Ladder Diagram, Structured Text and Grafcet
languages.
It also enables the setting up of application-specific functions, maintenance and diagnostics of the developed
applications. It includes PL7 2, PL7 3 and ORPHEE application converters.
Description
For PLCs
Licence type
Reference
Weight
kg
PL7 Junior software
packages
TSX Micro, Premium
Single (1 station)
TLX CD PL7J P45
–
Group (3 stations)
TLX CD3 PL7J P45
–
Software update for earlier
version PL7 Junior
software
TSX Micro, Premium
Single (1 station)
TLX RCD PL7J P45M
–
Group (3 stations)
TLX RCD3 PL7J P45M
–
Software upgrade
packages from earlier
version PL7 Micro
TSX Micro, Premium
Single (1 station)
TLX UCD PL7J P45M
–
PL7 Pro software packages
PL7 Pro software has identical functions to that of PL7 Junior software. In addition, it allows the user to create
their own DFB function blocks and graphic runtime screens.
Description
For PLCs
Licence type
Reference
Weight
kg
PL7 Pro software
packages
TSX Micro, Premium
Single (1 station)
TLX CD PL7P P45
–
Group (3 stations)
TLX CD3 PL7P P45
–
Software update for earlier
version PL7 Pro software
TSX Micro, Premium
Single (1 station)
TLX RCD PL7P P45M
–
Group (3 stations)
TLX RCD3 PL7P P45M
–
Software upgrade
packages from earlier
version PL7 Junior
TSX Micro, Premium
Single (1 station)
TLX UCD PL7P P45M
–
(1)
The configuration of the PC must correspond to the reference and version of the Windows operating system installed.
Note: The PC must have a CD-ROM drive.
