Software
Unity Pro software
Unity Loader software
Communication between the PC and the PLC
Unity Loader supports the following PC-PLC communications:
b
Quantum Unity Pro PLCs: Modbus communication, transfer of project
components only
b
Premium Unity Pro PLCs: Unitelway communication, transfer of project
components only
b
Modicon M340 PLCs and modules: Communication via Ethernet and USB ports,
transfer of project components and firmware. See table below.
Reference
Type of module
Ethernet port
USB port
BMX P34 2000
CPU with Modbus
BMX P34 2010/20103
CPU with CANopen
BMX P34 2020
CPU with integrated
Ethernet port
BMX P34 2030/20302
BMX NOE 0100/0110
Ethernet Modbus/TCP
BMX AMI/ART/AMO/AMM
Analogue I/O
BMX EHC 0200/0800
Counter
BMX MSP 0200
Motion control
Supported
Supported if CPU has integrated Ethernet port
For Ethernet networks, Unity Loader contains a network scanner which can be used
to scan a range of network addresses. Once a recognized Modicon M340 PLC has
been selected, data transfer operations can be performed.
References
Unity Loader is supplied with Unity Pro Small, Medium, Large and Extra Large.
It is also downloadable free of charge from our website
www.schneider-electric.com,download section.
Compatibility
Unity Loader is independent of Unity Pro and compatible with all Modicon M340 PLCs,
Unity Pro Quantum PLCs via Modbus and Unity Pro Premium PLCs via Unitelway. The
program files and PLC data files are compatible between Unity Pro and Unity Loader.
Description
Type
Reference
Weight
kg
Unity Loader software
Single licence
(1
station)
Software downloadable free of
charge from our website
www.schneider-electric.com–
Presentation
(
continued)
,
references
Unity Loader
