Presentation
(
continued)
Software
Unity Pro software
User-definable process control
User-definable process control
The process control offer integrated as standard in Premium platforms can be used
to set up and debug machine control-oriented control loops in Unity Pro Medium,
Large, Extra Large and XL Safety.
User-definable process control functions
Premium
TSX P57 2
p
4
M
/
2634
M
/
3
p
4
M
/
3634
M
/
454
M
/
4634
M
/
554
M
/
5634
M
/
6634
M
processors make it possible, depending on the model, to manage between 10 to 30
process control channels (of 3 loops each).
These channels can be configured to execute algorithms for industrial processes:
b
Cascaded loop
b
Process loop
b
Autoselective loop
b
Setpoint programmer
b
Controller with three simple loops
Inputs/Outputs
Premium
TSX P57 2
p
4
M
/
2634
M
/
3
p
4
M
/
3634
M
/
454
M
/
4634
M
/
554
M
/
5634
M
/
6634
M
processors manage an entire station consisting of racks connected on Bus X.
The I/O interfaces required for process control processing operations are analog or
discrete channels in:
b
In-rack I/O modules
b
Modicon OTB, STB or Momentum distributed I/O modules
Control loops
Software setup of the control loops is user-definable (Plug and Play technology)
during configuration of the Premium processor.
The user enters information in the predefined loop diagrams which also integrate
management of operating modes and the link with the I/O.
2
1
3
4
Functions:
pages 6/34 …
