Functional units
Installation
DD383870
Device
No. of
devices
No. of vertical
modules
Mounting plate Cut-out front
plate
Collar and
raiser
Compact NSX
NSX100/250 1
5
03415
03618
LV429284
NSX400/630 1
6
03462
(1)
03657
LV432534
Vigicompact NSX
Vigi NSX100/250 1
5
03415
03618
LV429285
Vigi NSX400/630
toggle, rotary
handle
1
6
03462
03657
LV429285
(1)
Catalogue number 03460 is recommended when installing an NSX with a motor mechanism.
Busbar connection
Linergy busbars
Dd383571
Device
Prefabricated connection
Adaptator + long terminal shields
Compact NSX and Vigicompact NSX
NSX100/250 3P
04427
LV429306 + LV429517
4P
04428
LV429307 + LV429518
NSX400/630 3P
must be made
LV432584 + LV432593
4P
must be made
LV432585 + LV432594
Toggle Compact NSX and Vigicompact NSX
NSX100/250 3P
04431
LV429306 + LV429517
4P
04432
LV429307 + LV429518
NSX400/630 3P
04461
LV432584 + LV432593
4P
04462
LV432585 + LV432594
Prefabricated connection + terminal shields.
Dd383572
Flat busbars
Device
Connection
Adaptator + long terminal shields
Compact NSX and Vigicompact NSX
NSX100/250 3P
must be made
LV429306 + LV429517
4P
must be made
LV429307 + LV429518
NSX400/630 3P
must be made
LV432584 + LV432593
4P
must be made
LV432585 + LV432594
Selection of flexible bars for the connection: see page B-54.
Long terminal shields.
Connection
Dd383573
Front connection
Rear connection
Device
Adaptator + long
terminal shields
or transfer assembly
(w/o connection)
+ adaptator
+ long terminal shields
Long insulated
terminals
Compact NSX and Vigicompact NSX
NSX100/250 3P
LV429306 +
LV429517
04429
+ LV429306
+ LV429517
LV429276
(1)
+
2 x LV429235 +
LV429236 +
LV429306
4P
LV429307 +
LV429518
04430
+ LV429307
+ LV429518
LV429277
(1)
+
2 x LV429235 +
2 x LV429236 +
LV429307
Transfer assembly (w/o connection) + long terminal shields.
NSX400/630 3P
LV432584 +
LV432593
04459
+ LV432584
+ LV432591
LV432526
(1)
+
2 x LV432475 +
LV432476 +
LV432584
4P
LV432585 +
LV432594
04460
+ LV432585
+ LV432592
LV432527
(1)
+
2 x LV432475 +
2 x LV432476 +
LV432585
(1)
Protection of terminals is ensured by Form 4 partitioning: see page B-32.
