78 / 356
A-26
Functional units
Installation
Device
No. of vertical
modules
Mounting plate Cut-out front
plate
Collar and raiser
Dd383562
Fixed or plug-in Compact NSX
NSX100/250 3P 3
03413
03604
4P 4
03414
03606
NSX400/630
(1)
3P 4
03453
(2)
03643
4P 5
03454
(2)
03644
Fixed or plug-in Vigicompact NSX
NSX100/250 3P 3
03413
03604
LV429285
Rotary handle
4P 4
03414
03606
LV429285
NSX100/250 3P 3
03413
03604
LV429285
Motor mech.
4P 4
03414
03606
LV429285
NSX400/630
(1)
3P 4
03453
03643
LV429285
Rotary handle
4P 5
03454
03644
LV429285
(1)
For direct installation under horizontal busbars, the busbars must be covered: see page B-28.
(2)
Catalogue number
03460
is recommended when installing an NSX with a motor mechanism.
Busbar connection
Linergy busbars
Dd383563
Device
Prefabricated connection
Terminal shields
Fixed Compact NSX and Vigicompact NSX
NSX100/250 3P
04427
LV429515
4P
04428
LV429516
NSX400/630 3P
must be made
LV432591
4P
must be made
LV432592
Plug-in Compact NSX and Vigicompact NSX
NSX100/250 3P
04427
LV429306 + LV429517
4P
04428
LV429307 + LV429518
NSX400/630 3P
must be made
LV432584 + LV432591
4P
must be made
LV432585 + LV432592
Prefabricated connection + terminal shields.
Dd383564
Flat busbars
Device
Connection
Terminal shields
Fixed Compact NSX and Vigicompact NSX
NSX100/250 3P
must be made
LV429515
4P
must be made
LV429516
NSX400/630 3P
must be made
LV432591
4P
must be made
LV432592
Plug-in Compact NSX and Vigicompact NSX
NSX100/250 3P
must be made
LV429306 + LV429517
4P
must be made
LV429307 + LV429518
NSX400/630 3P
must be made
LV432584 + LV432591
4P
must be made
LV432585 + LV432592
Terminal shields.
Selection of flexible bars for the connection: see page B-54.
Connection
Device
Front connection
Rear connection
Adaptator +
long terminal
shields
or transfer assembly
(w/o connection)
+ adaptator + long
terminal shields
Short terminal
shields
Long insulated
terminals
DD383565
Fixed Compact NSX and Vigicompact NSX
NSX100/250 3P
LV429517
04429
+ LV429515 LV429515
(1)
Vigi NSX100/250 4P
LV429518
04430
+ LV429516 LV429516
(1)
NSX400/630 3P
LV432593
04459
+ LV432591 LV432591
(1)
Vigi NSX400/630 4P
LV432594
04460
+ LV432592 LV432592
(1)
Plug-in Compact NSX and Vigicompact NSX
NSX100/250 3P
LV429306 +
LV429517
04429
+ LV429306
+ LV429517
LV429276
(1)
+ 2 x
LV429235 +
LV429236 +
LV429306
Vigi NSX100/250 4P
LV429307 +
LV429518
04430
+ LV429307
+ LV429518
LV429277
(1)
+
2 x
LV429235 + 2 x
LV429236 +
LV429307
Transfer assembly (w/o connection) + long terminal shields
NSX400/630 3P
LV432584 +
LV432593
04459
+ LV432584
+ LV432591
LV432526
(1)
+ 2 x
LV432475 +
LV432476 +
LV432584
Vigi NSX400/630 4P
LV432585 +
LV432594
04460
+ LV432585
+ LV432592
LV432527
(1)
+ 2 x
LV432475 + 2 x
LV432476 +
LV432585
(1)
Protection of terminals is ensured by Form 4 partitioning: see page B-32.
Compact NSX100 to NSX630
Horizontal
Rotary handle, motor mechanism
Fixed, plug-in
Circuit breakers
