79 / 356
A-27
Functional units
Installation
Device
No.
dev.
No. of
vertical
modules
(1)
Mounting
plate
Cut-out
front plate
Upstream
front plate
Downst.
front
plate
Collar and
raiser
Dd383566
Fixed Compact NSX
NSX100/160
3/4 6
03422
03243
03801
NSX250
3/4 7
03422
03243
03802
NSX400
1 11
03461
(2)
03275 03801
03801
NSX400
2 11
03461
(2)
03663
03802
03803
NSX630
1 13
03461
(2)
03275 03802
03802
NSX630
2 13
03461
(2)
03663
03803
03804
Fixed Vigicompact NSX
Vigi NSX100/160 3/4 8
03422
03244
03801
LV429285
Vigi NXS250
3/4 9
03422
03244
03802
LV429285
Vigi NSX400
(rot )
1 13
03461 03297
03802
LV429285
Vigi NSX400
(rot )
2 13
03461
03666
03802
03803
LV429285
Vigi NSX630
(rot )
1 15
03461 03297
03801
03803
LV429285
Vigi NSX630
(rot )
2 15
03461 03666
03803
03804
LV429285
Plug-in Compact NSX
Dd383567
NSX100/160
3/4 7
03421
03243 03801
03801
NSX250
3/4 8
03421
03243 03801
03802
NSX400
1 11
03461
(2)
03275 03801
03801
NSX400
2 11
03461
(2)
03663
03802
03803
NSX630
1 13
03461
(2)
03275 03802
03802
NSX630
2 13
03461
(2)
03663
03803
03804
Plug-in Vigicompact NSX
Vigi NSX100/160 3/4 9
03421
03244
03801
03801
LV429285
Vigi NSX250
3/4 10
03421
03244
03801
03802
LV429285
Vigi NSX400
(rot )
1 13
03461 03297
03802
LV429285
Vigi NSX400
(rot )
2 13
03461 03666
03802
03803
LV429285
Vigi NSX630
(rot )
1 15
03461 03297
03801
03803
LV429285
Vigi NSX630
(rot )
2 15
03461 03666 03803
03804
LV429285
(1)
For the Compact NSX100/250, the number of modules indicated is for supply via a Polypact
distribution block. For supply via cables, two additional modules are required; add an upstream
plain front plate (03802).
(2)
Catalogue number 03460 is recommended when installing an NSX with a motor mechanism.
Accessories
Blanking plates: see page C-23.
Busbar connection
Linergy busbars
Dd383568
Device
No. of
devices
Polypact
(with connection)
Polypact
(with connection)
Adaptator
Fixed device
Plug-in device
Fixed or plug-in Compact NSX and Vigicompact NSX
NSX100/250
4 x 3P
04405
04405
+
LV429306
3 x 4P
04406
04406
+
LV429307
Flat busbars
Device
No. of
devices
Polypact
(w/o connection)
Polypact
(w/o connection)
Adaptator
Fixed device
Plug-in device
Fixed or plug-in Compact NSX and Vigicompact NSX
NSX100/250
4 x 3P
04407
04407
+
LV429306
Insulated distribution block with connection.
3 x 4P
04408
04408
+
LV429307
Accessories
Cat. no.
Polypact tooth-caps
04809
Polypact distribution block: see page B-52.
Connection
Dd383569
Front connection Rear connection
Device
Adaptator + long
terminal shields
Short terminal
shields
Long insulated terminals
Fixed Compact NSX and Vigicompact NSX
NSX100/250 3P
LV429517
LV429515
(1)
4P
LV429518
LV429516
(1)
NSX400/630 3P
LV432593
LV432591
(1)
4P
LV432594
LV432592
(1)
Plug-in Compact NSX and Vigicompact NSX
NSX100/250 3P
LV429306 + LV429517
LV429276
(1)
+ 2 x LV429235
+ LV429236 + LV429306
4P
LV429307 + LV429518
LV429277
(1)
+ 2 x LV429235
+ 2 x LV429236 + LV429307
NSX400/630 3P
LV432584 + LV432593
LV432526
(1)
+ 2 x LV432475
+ LV432476 + LV432584
Front connection with long terminal shields.
4P
LV432585 + LV432595
LV432527
(1)
+ 2 x LV432475
+ 2 x LV432476 + LV432585
(1)
Size reduced one module downstream.
Protection of terminals is ensured by Form 4 partitioning: see page B-32.
Compact NSX100 to NSX630
Vertical
Rotary handle, motor mechanism
Fixed, plug-in
Circuit breakers
