62 / 356
A-10
Functional units
Device installation
DD380647
DD380836
DD380852
DD380853
DD380854
Device
No. of
vert.
mod.
Mounting
plate
Cut-out
front plate
Upstream
front plate
Downstream
front plate
Fixed device
NT06/10
front conn.
cables 12
03484
03692
03802
03803
Canalis 17
03484
03692
03804 +
03803
03803
NT12
front conn.
cables 14
03484
03692
03804
03803
Canalis 17
03484
03692
03804 +
03803
03803
NT16
front conn.
cables 14
03484
03692
03804
03803
NT06/16
rear conn.
cables 11
03484
03692
03801
03803
Canalis 16
03484
03692
03806
03803
Drawout device
NT06/10
front conn.
cables 13
03483
03691
03802
03803
Canalis 18
03483
03691
03804 +
03803
03803
NT12
front conn.
cables 15
03483
03691
03804
03803
Canalis 18
03483
03691
03804 +
03803
03803
NT16
front conn.
cables 15
03483
03691
03804
03803
NT06/16
rear conn.
cables 11
03483
03691
03803
Canalis 16
03483
03691
03805
03803
Distribution
Linergy busbars
DD380648
DD380855
DD380856
Device
Front connectors Prefabricated
connection
Cover for BB
connection
Fixed device
NT06/12
3P
b
04475
04926
4P
b
04476
04926
NT16
3P
b
04489
04926
4P
b
04490
04926
Drawout device
NT06/12
3P
b
04477
04926
4P
b
04478
04926
NT16
3P
b
04491
04926
4P
b
04492
04926
Note:
To make measurements:
install the CTs on the horizontal busbars (busbar connection); in this case, an additional
module is required; add a plain front plate (03801)
or install a Micrologic control unit capable of displaying the values
.
Selection of Linergy busbars
: see page B-11.
b
b
DD380649
Flat busbars
DD380855
DD380857
DD380840
Device
Front connectors Connection
Free support for
BB connection
Cover for BB
connection
Fixed device
NT06/16
b
must be made
04662 x 2
04926
Drawout device
NT06/16
b
must be made
04662 x 2
04926
Note:
To make measurements:
install the CTs on the horizontal busbars (busbar connection); in this case, an additional
module is required; add a plain front plate (03801)
or install a Micrologic control unit capable of displaying the values.
Selection of flat busbars
: see page B-18.
b
b
Masterpact NT06 to NT16
Toggle and motor mechanism
Circuit breakers
version: 3.0
400E21110.indd
