Functional units
Masterpact NW08 to NW32
Dedicated cubicle
Connection
Bottom connection using cables
DD383723
DD380838
DD382941
DD380830
Device
Vertical rear
connection
Terminal
extension bars
for connection
Terminal
extension bar
supports
Cable
cover
(1)
Fixed/drawout device
NW08/32
b
must be made
04694 x 2
04861
(1)
Form 1 cable cover, see page B-25.
