Connection
Flat bars, 10 mm thick
Device Permissible current (A)
Ambient temperature around the switchboard
25 °C 30 °C 35 °C 40 °C 45 °C 50 °C
IP y 31 IP > 31 IP y 31 IP > 31 IP y 31 IP > 31 IP y 31 IP > 31 IP y 31 IP > 31 IP y 31 IP > 31
NT06 Size per phase 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 b
I (A) 630 630 630 630 630 630 630 630 630 630 630
NT08 Size per phase 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 b
I (A) 800 800 800 800 800 800 800 800 800 800 800
NT10 Size per phase 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 b
I (A) 1000 1000 1000 1000 1000 1000 1000 1000 1000 960 1000
NT12 Size per phase 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 b
I (A) 1250 1250 1250 1250 1250 1210 1250 1160 1210 1110 1160
NT16 (1) Size per phase 2b 50 x 10 2b 50 x 10 2b 50 x 10 2b 50 x 10 2b 50 x 10 2b 50 x 10 2b 50 x 10 2b 50 x 10 2b 50 x 10 2b 50 x 10 2b 50 x 10 b
I (A) 1560 1430 1520 1430 1480 1380 1430 1330 1380 1280 1330
(1) Make the neutral connection with one bar, 50 x 10 mm.
Horizontal link
Flat bars, 10 mm thick
Device Permissible current (A)
Ambient temperature around the switchboard
25 °C 30 °C 35 °C 40 °C 45 °C 50 °C
IP y 31 IP > 31 IP y 31 IP > 31 IP y 31 IP > 31 IP y 31 IP > 31 IP y 31 IP > 31 IP y 31 IP > 31
NT06 Size per phase 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 b
I (A) 630 630 630 630 630 630 630 630 630 630 630
NT08 Size per phase 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 b
I (A) 800 800 800 800 800 800 800 800 800 800 800
NT10 Size per phase 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 1b 50 x 10 b
I (A) 1000 1000 1000 1000 1000 1000 1000 1000 1000 960 1000
NT12 Size per phase 1b 60 x 10 1b 60 x 10 1b 60 x 10 1b 60 x 10 1b 60 x 10 1b 60 x 10 1b 60 x 10 1b 60 x 10 1b 60 x 10 1b 60 x 10 1b 60 x 10 b
I (A) 1250 1250 1250 1250 1250 1210 1250 1160 1210 1110 1160
NT16 Size per phase 1b 80 x 10 1b 80 x 10 1b 80 x 10 1b 80 x 10 1b 80 x 10 1b 80 x 10 1b 80 x 10 1b 80 x 10 1b 80 x 10 1b 80 x 10 1b 80 x 10 b
I (A) 1560 1430 1520 1430 1480 1380 1430 1330 1380 1280 1330
b connection not possible.
Note: the values indicated above have been validated for Prisma Plus switchboards.
