D-27
Compact NS630b to NS1600,
vertically mounted
Dd383537
Using the data below, it is possible to determine the permissible current for a
prefabricated connection between a vertical Compact NS630b/NS1600, fixed or
withdrawable, and Linergy busbars depending on the ambient temperature around
the switchboard and the IP value.
Fixed
Prefabricated connections
Device and Cat. no.
Permissible current (A)
Ambient temperature around the switchboard
25 °C
30 °C
35 °C
40 °C
45 °C
50 °C
IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31
NS630b 3P Cat. no. 04485 630
630
630
630
630
630
630
630
630
630
630
b
4P Cat. no. 04486
NS800 3P Cat. no. 04485 800
800
800
800
800
800
800
800
800
800
800
b
4P Cat. no. 04486
NS1000 3P Cat. no. 04485 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
b
4P Cat. no. 04486
NS1250 3P Cat. no. 04485 1250 1250 1250 1250 1250 1250 1250 1200 1250 1150 1200
b
4P Cat. no. 04486
NS1600 3P Cat. no. 04487 1600 1550 1600 1500 1550 1450 1500 1400 1450 1350 1400
b
4P Cat. no. 04488
Withdrawable
Prefabricated connections
Device and Cat. no.
Permissible current (A)
Ambient temperature around the switchboard
25 °C
30 °C
35 °C
40 °C
45 °C
50 °C
IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31
NS630b 3P Cat. no. 04477 630
630
630
630
630
630
630
630
630
630
630
b
4P Cat. no. 04478
NS800 3P Cat. no. 04477 800
800
800
800
800
800
800
800
800
800
800
b
4P Cat. no. 04478
NS1000 3P Cat. no. 04477 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
b
4P Cat. no. 04478
NS1250 3P Cat. no. 04477 1250 1250 1250 1250 1250 1250 1250 1200 1250 1150 1200
b
4P Cat. no. 04478
NS1600
3P Cat. no. 04491 1560 1480 1520 1430 1480 1380 1430 1330 1380 1280 1330
b
4P Cat. no. 04492
b
connection not possible.
Example
For a fixed Compact NS1600, 4P, where the ambient temperature around the
switchboard is 35 °C and the IP > 31
:
The maximum permissible current for the prefabricated connection (04488) is 1450 A.
Note:
the values indicated above have been validated for Prisma Plus switchboards.
