276 / 356
D-28
Masterpact NT06 to NT16,
vertically mounted
DD383666
Using the data below, it is possible to determine the permissible current for a
prefabricated connection between a vertical Masterpact NT06/NT16, fixed or
drawout, and Linergy busbars depending on the ambient temperature around the
switchboard and the IP value.
Fixed
Prefabricated connections
Device and Cat. no.
Permissible current (A)
Ambient temperature around the switchboard
25 °C
30 °C
35 °C
40 °C
45 °C
50 °C
IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31
NT06 3P Cat. no. 04475 630
630
630
630
630
630
630
630
630
630
630
b
4P Cat. no. 04476
NT08 3P Cat. no. 04475 800
800
800
800
800
800
800
800
800
800
800
b
4P Cat. no. 04476
NT10 3P Cat. no. 04475 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
b
4P Cat. no. 04476
NT12 3P Cat. no. 04475 1250 1250 1250 1250 1250 1250 1250 1200 1250 1150 1200
b
4P Cat. no. 04476
NT16 3P Cat. no. 04489 1600 1570 1600 1520 1570 1470 1520 1420 1470 1370 1420
b
4P Cat. no. 04490
Withdrawable
Prefabricated connections
Device and Cat. no.
Permissible current (A)
Ambient temperature around the switchboard
25 °C
30 °C
35 °C
40 °C
45 °C
50 °C
IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31 IP
y
31 IP > 31
NT06 3P Cat. no. 04477 630
630
630
630
630
630
630
630
630
630
630
b
4P Cat. no. 04478
NT08 3P Cat. no. 04477 800
800
800
800
800
800
800
800
800
800
800
b
4P Cat. no. 04478
NT10 3P Cat. no. 04477 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
b
4P Cat. no. 04478
NT12 3P Cat. no. 04477 1250 1250 1250 1250 1250 1250 1250 1200 1250 1150 1200
b
4P Cat. no. 04478
NT16 3P Cat. no. 04491 1560 1480 1520 1430 1480 1380 1430 1330 1380 1280 1330
b
4P Cat. no. 04492
b
connection not possible.
Example
For a drawout Masterpact NT16 , 4P, where the ambient temperature around the
switchboard is 35 °C and the IP > 31
:
The maximum permissible current for the prefabricated connection (04492) is 1380 A.
Note:
the values indicated above have been validated for Prisma Plus switchboards.
Designing connections
u
630 A
Prefabricated connections for Linergy
busbars
Additional informations
Designing electrical
characteristics
