B-29
Distribution
Form 2 partitioning
Main distribution
Running of auxiliary wires
We recommend running all auxiliary wires in trunking or straps.
In Prisma Plus cubicles, the wires can be run in any combination of three
directions (vertical, horizontal widthwise and horizontal depthwise) to ensure
optimum and rational wiring layouts.
Auxiliary wiring knock-outs
With Prisma Plus, the top and bottom partitioning plates of the lateral vertical
busbars are equipped with knock-outs designed for the passage of two 30 x 60
mm trunking sections.
These plates are reversible front and back to adapt to auxiliary wires running in
the front or rear of the cubicles.
DD384013
DD384014
JdB < 80 mm
DD384062
