Functional units
One 144 x 144 mm device
+ four 72 x 72 mm devices
Installation
Devices are installed in the device compartment on a metal front plate with cut-outs.
Blanking plates clip onto the unused 72 x 72 mm holes.
DD381712
Cat. no. selection
Designation
Cat. no.
Metal front plate with cut-outs, 4 modules (for one 144 x 144 mm device
+ four 72 x 72 mm devices)
03912
Blanking plate (for 72 x 72 mm hole)
03907
DD382635
The blanking plates have knock-outs (22 mm diameter) to install:
1
to 2 lamps or pushbuttons
1 switch
1 emergency off (EPO) pushbutton.
b
b
b
Pushbuttons or lamps
Installation
In the device compartment on a metal front plate with cut-outs.
DD381690
Cat. no. selection
Designation
Cat. no.
Metal front plate with knock-outs (2 modules) for twelve 22 mm diameter
lamps or pushbuttons
03914
Human-switchboard interface
144 x 144 mm devices
22.2 mm diameter lamps, pushbuttons
Others
