Functional units
72 x 72 mmmeasurement devices
On an interface with plastic mounting plates
DD381705
Cat. no. selection
Designation
Cat. no.
Front plate with cut-outs, 3 modules (for 5 plastic mounting plates)
03904
Plastic mounting plate with cut-out (for 72 x 72 mm device)
03902
Plain plastic mounting plate
03900
DD382575
The plain plastic mounting plates have knock-outs:
4 holes, 16 mm diameter
5 holes, 22 mm diameter
1 hole, 45 x 45 mm
b
b
b
DD381689
On a metal front plate with cut-outs
Cat. no. selection
Designation
Cat. no.
Metal front plate with cut-outs, 3 modules (for six 72 x 72 mm devices)
03910
Blanking plate (for 72 x 72 mm hole)
03907
DD382637
The blanking plates have knock-outs:
3 holes, 22 mm diameter
1 hole, 45 x 45 mm
b
b
96 x 96 mmmeasurement devices
On an interface with plastic mounting plates
DD382632
Cat. no. selection
Designation
Cat. no.
Front plate with cut-outs, 3 modules (for 4 plastic mounting plates)
03904
Plastic mounting plate with cut-out (for 96 x 96 mm device)
03903
(1)
Plain plastic mounting plate
03901
(1)
Not designed for Power meter PM700/800 installation.
DD382633
The plain plastic mounting plates have knock-outs:
4 holes, 16 mm diameter
5 holes, 22 mm diameter
1 hole, 45 x 45 mm
1 hole, 72 x 72 mm
b
b
b
b
Human-switchboard interface
72 x 72 and 96 x 96 mm devices
Others
