115 / 356
A-63
Functional units
Tego Power
Dd381167
Device
No. of
vertical
modules
Mounting
plate
Transparent
front plate
Upstream
front plate
Downstream
front plate
Tego Power
Tego Power 2 to 8
feeders
8
03576
03343
03801
03801
ATS01 soft starters
DD383842
Device
No. of
vertical
modules
Useful length of rail
(mm)
Modular rail
(adjustable)
Plain front plate
On a modular rail
ATS01N103/106FT 4
432 mm
03402
03804
ATS01N109/112FT 5
432 mm
03402
03805
ATS01N206
to
212 5
432 mm
03402
03805
ATS01N222
to
232 6
432 mm
03402
03806
ATS01N 230LY 5
432 mm
03402
03805
ATS01N 244LY 5
432 mm
03402
03805
ATS01N 244Q 5
432 mm
03402
03805
Width of devices:
ATS01N103/106FT : 22.5 mm
ATS01N109/112FT : 45 mm
ATS01N206 to 212 : 45 mm
ATS01N222 to 232 : 45 mm
ATS01N230LY : 180 mm
ATS01N244LY : 180 mm
ATS01N244Q : 180 mm
DD383817
Device
No. of
vertical
modules
Slotted mounting
plate
Plain front plate
On a slotted plate
ATS01N272LY
6
03572
03806
ATS01N285LY
6
03572
03806
ATS01N272Q 6
03572
03806
ATS01N285Q 6
03572
03806
Width of devices:
ATS01N272LY : 180 mm
ATS01N285LY : 180 mm
ATS01N272Q : 180 mm
ATS01N285Q : 180 mm
Alimentation and LV/LV
transformer
DD381169
Device
No. of
vertical
modules
Slotted mounting
plate
Plain front plate
LV/LV transformer
ABL6-TS/TD up to
2500 VA
4
03571
03804
LV/LV alimentation
ABL6-RT up to
960 W
4
03571
03804
ABL6-RF up to
480 W
4
03571
03804
Industrial control devices
Others
