Building automation - door communication & access control

12 / 16

12 Building Automation 0115 ABB Low Voltage
Description Part No
Product Hierarchy
900004 Order Code
Sealing strip
Spare part for the outdoor station.
Temperature range (Device): -25 °C to 55 °C 83530-500 8300-0-0134
Mounting tool
Spare part for the outdoor station. 83510-500 8300-0-0129
Description Part No
Product Hierarchy
900004 Order Code
Audio compact set for One-family house
Indoor station to match the future® linear switch range in studio white, outdoor station:
stainless steel
Consisting of outdoor audio station, 1 gang 83101/1-660-500.
Consisting of outdoor surface-mounted installation box 83401 AP-681-500.
Consisting of indoor audio station with display 83200 U-500.
Consisting of cover plate 83260-84-500.
Consisting of system controller 83300-500.
Consisting of 2gang frame 1722-184K.
83004/1-500 8300-0-0142
Audio compact set for Two-family house
Indoor station to match the future® linear switch range
in studio white, outdoor station: stainless steel
Consisting of outdoor audio station, 2 gang 83101/2-660-500.
Consisting of outdoor surface-mounted installation box 83401 AP-681-500.
Consisting of 2 x indoor audio station with display 83200 U-500.
Consisting of 2 x cover plates 83260-84-500.
Consisting of system controller 83300-500.
Consisting of 2 x 2gang frame 1722-184K.
83004/2-500 8300-0-0143
Video compact set for One-family house
ABB-WelcomeTouch in studio white matt, outdoor station: stainless steel
Consisting of outdoor video station, 1 gang 83121/1-660-500.
Consisting of outdoor surface-mounted installation box 83402 AP-681-500.
Consisting of ABB-WelcomeTouch 83220 AP-624-500.
Consisting of system controller 83300-500.
83022/1-500 8300-0-0150
Video compact set for Two-family house
ABB-WelcomeTouch in studio white matt, outdoor station: stainless steel
Consisting of outdoor video station, 2 gang 83121/2-660-500.
Consisting of outdoor surface-mounted installation box 83402 AP-681-500.
Consisting of 2 x ABB-WelcomeTouch 83220 AP-624-500.
Consisting of system controller 83300-500.
83022/2-500 8300-0-0151
Catalogue 2014/2015 | Door Communication 475
