10 Building Automation 0115
ABB Low Voltage
Description
Part No
Product Hierarchy
900004 Order Code
Flush-mounting box
- For mounting in plastered facades.
Offers mounting points for the flush-mounted installation box.
Size 1/2
83551-500
8300-0-0349
Size 1/3
83552-500
8300-0-0350
Size 1/4
83553-500
8300-0-0351
Size 2/3
83554-500
8300-0-0352
Cavity wall set
For cavity wall mounting of the flush-mounted wall boxes.
83511-500
8300-0-0309
Surface-mounted installation box
For surface-mounted installation of ABB-Welcome outdoorstation.
Protection class (Device): IP 44
681 anthracite - size 1/2
83401 AP-681-500
8300-0-0116
689 light grey - size 1/2
83401 AP-689-500
8300-0-0112
681 anthracite - size 1/3
83402 AP-681-500
8300-0-0117
689 light grey - size 1/3
83402 AP-689-500
8300-0-0113
681 anthracite - size 1/4
83403 AP-681-500
8300-0-0118
689 light grey - size 1/4
83402 AP-689-500
8300-0-0114
681 anthracite - size 2/3
83404 AP-681-500
8300-0-0119
689 light grey - size 2/3
83404 AP-689-500
8300-0-0115
DIN A 4 labelling sheet
Transparent
1799/03
1799-0-0960
Base call button module
Spare part for the outdoor station.
Stamped labelling foil is enclosed.
Protection class (Device): IP 44
Temperature range (Device): -25 °C to 55 °C
1 gang
83140/1-500
8300-0-0106
2 gang
83140/2-500
8300-0-0107
3 gang
83140/3-500
8300-0-0108
Auxiliary call button module
Spare part for the outdoor station.
Stamped labelling foil is enclosed.
Protection class (Device): IP 44
Temperature range (Device): -25 °C to 55 °C
1 gang
83141/1-500
8300-0-0109
2 gang
83141/2-500
8300-0-0110
3 gang
83141/3-500
8300-0-0111
Audio module
Spare part for the outdoor station or as supplement for the audio module assembly.
Temperature range (Device): -25 °C to 55 °C
83500-500
8300-0-0232
Camera module
Allows the integration of the ABB-Welcome installation in letter boxes and bell systems
of different manufacturers, such as in the products of Erwin Renz Metallwarenfabrik
GmbH & Co KG, Boschstr. 3, 71737 Kirchberg/Murr.
The cutout for the camera must be created by the manufacturer.
Extended audio module assembly with video function.
Video camera with automatic day/night switchover and infrared LEDs to illuminate the
night shots.
Installed heating to keep the lens free of condensation.
Vertical/horizontal detection angle: 86°/67°
Setting angle horizontal/vertical: +/-15°, mechanically adjustable
Consumer units: 4
Temperature range (Device): -25 °C to 55 °C
83501-101-500
8300-0-0331
Building automation
ABB - Welcome door system accessories
Product
Article-No.
Order-No.
Pack/Qty
Product
Article-No.
Order-No.
