Invicta 3 Type B Distribution Boards
125A & 250A Side Extension Boxes
Side Extension Boxes for 125A Primary Boards
Description Cat ref.
Plain door
4 Way Side Extension Box for JK104B Full Width JK104BSF
6 Way Side Extension Box for JK106B Full Width JK106BSF
8 Way Side Extension Box for JK108B Full Width JK108BSF
12 Way Side Extension Box for JK112B Full Width JK112BSF
16 Way Side Extension Box for JK1116B Full Width JK116BSF
Side Extension Boxes for 250A Primary Boards
Description Cat ref.
Plain door
8 Way Side Extension Box for JK208B Full Width JK208BSF
12 Way Side Extension Box for JK212B Full Width JK212BSF
16 Way Side Extension Box for JK216B Full Width JK216BSF
18 Way Side Extension Box for JK218B Full Width JK218BSF
24 Way Side Extension Box for JK224B Full Width JK224BSF
Half Width Side Extension Boxes for 125/250A Primary Boards
Doors are not available.
Description Cat ref. Cat ref
125A 250A
4 Way Half Width Extension Box JK104BSH -
6 Way Half Width Extension Box JK106BSH -
8 Way Half Width Extension Box JK108BSH JK208BSH
12 Way Half Width Extension Box JK112BSH JK212BSH
16 Way Half Width Extension Box JK116BSH JK216BSH
18 Way Half Width Extension Box - JK218BSH
24 Way Half Width Extension Box - JK224BSH
Small Half Width Filler Box JK101BSH JK201BSH
Side extension boxes provide
a new concept for distribution
boards to allow cable ways to be
fitted on site.
These are available in either half
or full distribution board width.
Can be used with Invicta 3
Panelboards JN & JF.
All Side Extension Boxes
supplied with 2x removable
gland plates.
Complies with BS EN 62208.
For dimensions see page 3.43.
JK104BSF
JK104BSH
