General Catalogue • Enclosures • Technical
Insulated & Hybrid
DIN Rail Enclosure Dimensions
Insulated Enclosures
Enclosure
Size
Dimensions (mm)
Fixing Centres (mm)
Width Height Depth A B C D E
F
VC201
110 180 94
-
-
-
-
-
-
VC202
110 180 94
-
-
-
-
-
-
3
240 245 105 115 50
45
72
145 160
4
310 245 105 115 50
45
107 215 230
5
380 245 105 115 50
45
143 285 302
6
490 245 105 115 50
45
195 395 410
Hybrid Enclosures
Enclosure Size
Dimensions (mm)
Fixing Centres (mm)
Width Height Depth A B C D E
VH201
168 193 124 -
-
-
-
-
VH202
168 193 124 -
-
-
-
-
2
220 230 110 165 32
55
N/A 163
3
240 245 120 150 55
30
89
178
4
310 245 120 150 55
30
125 250
5
380 245 120 150 55
30
160 320
6
490 245 120 150 55
30
214 429
CUT-OUTS
Width
F
E
C
D
D
C
B
A
Height
Depth
Width
Height
Depth
E
A
B
C
D
D
C
