Dimensions
Orion Plus GRP Enclosures IP65
GRP Enclosure Dimensions
Dimensions (mm)
Inside Fixing
Outside Fixing
References Rows
A
H
B
C
D
E
F
E1
E2
F1
F2
FL201B
1
250
300
160
-
-
-
-
-
-
-
-
FL204B
2
300
350
160
250
300
219
258
339
339
269
389
FL209B
3
300
500
200
250
450
219
408
339
339
419
539
FL213B
3
400
500
200
350
450
319
408
439
439
419
539
FL216B
4
400
650
200
350
600
319
558
439
439
569
689
FL221B
4
500
650
250
450
600
419
558
539
539
569
689
FL229B
5
600
800
300
550
750
519
708
639
639
719
839
FL327B
-
850
1200 300
750
1050 -
-
-
-
-
-
Torque Settings
Pz No. (mm)
Cables >1.5mm
2
Tightening torque (N.m)
Cables ≤1.5mm
2
Tightening torque (N.m)
Cable Stripping
(mm)
Single Cable Multi Cables Single Cable Multi Cable
Consumer unit terminals
Earth and neutral terminal bars
2
6.5
2
2
1.5
1.5
10
Isolation
SB switch disconnectors
2
6.5
3.6
3.6
3.6
3.6
15
Circuit protection
MTN MCB
2
6.5
2.8
2.8
2.8
2.8
13
NBN/NCN/NDN MCB
2
6.5
2.8
2.8
2.8
2.8
13
RCBO
2
5.5
2.1
2.1
2.1
2.1
13
RCCB
2
5.5
2.8
2.8
2.8
2.8
13
235
B
A
F2
F
H
F1
D
C
E2
E1
E
Enclosures
