SM101E
SM101C
Current (TRMS)
I (1
st
CT)
5A...9999A
I (2
nd
CT)
5A
In
Calculated
Minimum measuring current (2
nd
CT)
5mA
Input consumption
<0.6VA per phase
Permanent overload (2
nd
CT)
6A
Accuracy
±0.2%
THD
±1%
Update period
1s
Voltage (TRMS)
U
50Vac...520Vac (Ph-Ph)
28Vac...300Vac (Ph-N)
Input consumption
<0.1VA per phase
Permanent overload (2
nd
CT)
760Vac
Accuracy
±0.2%
THD
±1%
Update period
1s
Power
Accuracy (P,Q)
±0.5%
Accuracy (S)
±1%
Accuracy (PF)
±0.02%
Update period
1s
Energy
Accuracy (Ea)
Class 0.5s
Accuracy (Er)
Class 2
Update period
1s
Frequency
F
45Hz...65Hz
Accuracy
±0.1%
Update period
1s
Supply
Voltage
200Vac...277Vac ±15%
Frequency
50/60Hz
Consumption
<5VA
Environment
Protection degree
IP51 (front panel)
IP20 (case)
Operating temperature
-10ºC to +55ºC
Storage temperature
-20ºC to +70ºC
Insulation category
III (300Vac Ph-Ph)
Degree of pollution
PD2
Communication
Metrological LED
N/A
0.1Wh/pulse
Pulse output
N/A
30Vdc/27mA Max
Communication
N/A
RS485
2/3 wires half duplex
Jbus/Modbus
2,400bds...38,400bds
Parity (no,odd,even)
1 or 2 Stop bytes
Connection
Network
1BL
2BL
3BL/3NBL
4BL/4NBL
Current/Voltage input
4mm
2
(solid or stranded)
Others
2.5mm
2
(solid or stranded)
Max torque
0.6Nm
Shape
Weight
205g
215g
Size
4M, 73mm x 90mm x 67mm
