CABLE MANAGEMENT
PERIMETER AND
DISTRIBUTION
For a full range of corresponding products,
see pages 361-370 in the product selector.
Standards and Approvals
EGA mini-trunking systems are manufactured
in accordance with the requirements of
BS EN 50085-1 and BS 4678 Part 4 and
achieve medium impact classification.
Red Alert mini-trunking complies with the
following:
BS 5839 Fire detection and alarm systems in
buildings (if used with fire product, ie. cables,
cables must still be secured with metal securing
clips
inside
trunking or trunking held with metal clip
around
trunking to comply with BS 5839 Part 1).
BS 4662 Boxes for the enclosure of electrical
accessories BS EN 50085-1 and BS 4678 Part 4
Cable trunking made of insulating material.
All systems comply with all relevant
requirements of the latest Edition of the IET
Wiring Regulations.
Ega Mini Trunking systems are Class 1Y for
spread of flame when tested in accordance with
BS 476 Part 7.
521.200 Wiring systems in escape routes.
Trunking systems – MK recommends the use of
existing metallic cable retention systems when
using trunking in escape routes.
TECHNICAL SPECIFICATION
MATERIALS
PVCu materials used in the manufacture of
MK products are self extinguishing non-flame
propagating in accordance with BS 4678 Part 4.
Extrusion material has been tested by a UKAS
accredited laboratory in accordance with the
requirements of BS 476 Part 7 and has achieved a
Class 1Y.
Moulding material has been tested by a UKAS
accredited laboratory and conforms with IEC 695-2-1
at a severity of 650°C.
IET WIRING REGULATIONS
Designed and manufactured to comply in all respects
with BS 7671:2008 (IET Wiring Regulations 17th
Edition: 2008)
QUALITY ASSURANCE
The system is manufactured to BS EN ISO 9001
Classifications to BS EN 50085-1:2005 and
BS EN 50085-2-1:2006 available on request
FEATURES
l
Wide range of trunking profiles
l
Red Alert profile for alarm circuits
l
Wide range of integrated components maximises versatility of application
l
Unobtrusive and neat
l
Easy to assemble and install
l
Durable and impact resistant to Medium Classification BS EN 50085-1 and
BS 4678 Part 4
l
Communication trunking for voice and data
l
Speedfix options allow fast installation
l
All extrusions manufactured from 100% recycled material*
Ega Mini Trunking
Technical
Ega Mini, Communication and Red Alert Trunking
* Based on 2014 consumption
