FLOOR SYSTEMS
RAISED
Cablelink Plus Modular
Technical
100
65.5
124
41.5
8
8
47
47
DIMENSIONS (mm)
3 MODULE
4 MODULE
A
287
362
B
287
287
C*
266
341
D*
266
266
* Tile cut out general tolerance = +1.5mm.
The table below shows the sizes required
for the carpet lid infill for the Cablelink Plus
Modular floorboxes.
265X265mm 340x265mm
X Y X Y
Carpet Infill (mm) 251 219 326 219
Knockouts
END KNOCKOUT
(CONDUIT ENTRY)
SIDE KNOCKOUT
(INTERLINK)
20mm 25mm
20mm
Power
2
–
2
Non-Power
1
1
2
6 x LJU6C Only
(CRM21301)
–
2
2
Cat 6 and Cat 7 Compatibility
With the introduction of Cat 6 and Cat 7 data cabling the
orientation and depth of many data outlets has changed resulting
in the need for greater backbox depths and wiring space to
accommodate these longer data outlet. No longer is a 35mm
wiring space sufficient to ensure data terminations can be made
to the manufacturer’s recommendations to prevent transmission
losses. As a result MK has introduced 45mm wiring space for the
Cablelink Plus floorbox systems (as well as for the Prestige 3D
wall trunking system).This easily accommodates the longer Cat
6 and Cat 7 data outlets and leaves sufficient space for the data
cable to run underneath it.
A
B
C
D
X
A
Y
B
Floorbox: Tile and Frame and Floor Tile Cut-Out Dimensions for 3 and 4 Modules Box
Cablelink Plus Module Dimensions
MINIMUM DEPTH (mm)
MAXIMUM DEPTH (mm)
221.0
221.0
154.0
77.0
42.0
47.0
186.0
186.
221.0
221.0
154.0
77.0
42.0
47.0
186.0
186.0
CRM11750
CRM11730
Cablelink Plus Modular Floorbox
