K1402M
INSTALLATION:
The dimmer module is designed for mounting into distribution and
consumer units containing 35 mm DIN rail according to EN50022.
Please observe the following points during installation:
● All master and slave dimmers must be connected to the same supply
phase.
● The mains supply to the dimmer(s) must be protected by a suitable fuse
or MCB rated no greater than 16A
● Do not exceed maximum control line length of 100m and do not run
slave control lines parallel to mains and network cables.
● Always observe the transformers recommended loading guidelines.
● Load transformers at or close to their full rated capacity. Do not connect
a small load to a larger transformers, (e.g. a 35W lamp on a 600VA
transformer)
● Ensure that slaves are wired to the correct control terminals and that
