Onix Plus™ Metal Power Grommet
The range of power grommets provide access to power in areas where standard plastic grommets are not robust
enough, where improved aesthetics are required, or a wet wash solution is required.
IP44 Wet Wash
Specifically designed to seal against water ingress to IP44 when the lid is closed, allowing the floor to be washed.
Onix Plus Metal Grommet Selector Guide
l Base – select preferred base depth (use for screed floors only)
l Grommet – choose finish of unserviced grommet
l Select either switched Socket Outlet or Unserviced Data Outlet to service the grommet
l Serviced Data Grommets are available via the Design Service
Screed Base Units
Part No. Description
NXGB100-1 Grommet Base Unit 55-80mm depth
NXGB100X-1 Grommet Base Unit 80-110mm
* A minimum finished floor thickness of 68mm is required. (Screed and floor tile thickness added together).
* Conduit entry only, not compatible with ducting.
Unserviced Data Grommets
Part No. Description
NXGCALD Unserviced Grommet with 1 x 50 x 75mm Euro aperture – Aluminium
NXGCBRD Unserviced Grommet with 1 x 50 x 75mm Euro aperture – Brass
NXGCNID Unserviced Grommet with 1 x 50 x 75mm Euro aperture – Nickel
Serviced Power Grommets*
Part No. Description
NXGCALP 13A 1G Switched Socket Outlet Grommet – Aluminium
NXGCBRP 13A 1G Switched Socket Outlet Grommet – Brass
NXGCNIP 13A 1G Switched Socket Outlet Grommet – Nickel
Socket outlets feature the MK Electric 3-pin operated safety shutter.
*Not dual earth. NXGCALP
MXGCALD
