MK Electric Catalogue No. 49

416 / 759

OUTLET BOX
l Option of two screed depths:
55-80mm and 80-110mm.
l Deeper screed depths available on request.
l Flat sided base design ensures a stronger screed solution and faster taping
l Optional 10mm plate height adjuster kit for greater screed depths to support
Cat 6 & Cat 6A compliance
l IP2X rated in accordance with BS EN 50085-1
OPTIONAL LOCKABLE LID
l Added security when
not in use
BASE FIXING FEET
l Fast fix installation
HANDLE
l Designed for
improved accessibility
OPTIONAL CABLE RETAINERS
l Acts as cable tidy to prevent
cables being trapped
OPTIONAL LID TETHER
l Added security
l Eliminates lid losses
STAGGERED PLATE
l Provides strain relief
clearance for moulded
plug tops
l Stagger only available
with 3 and 4 compartment
floorboxes
RATCHET LEVELLING SYSTEM
l Self levelling and rapid
fitting of frame and lid
ROBUST CORD CAPS
l Designed to improve
retention
Service Outlet Box
COMPARTMENT
SEGREGATION
LID
l Simple carpet cut out
l 8mm or 12mm (metal lid and trim)
recessed lids available
l Can be hinged from either of two sides
* SQUARE BOX OPTION
l 90º rotation of floorbox
for system flexibility
TESTED TO EN 50085-2-2
TO ACCEPT 5000N LOAD
* Only applicable for 200 x 200mm & 265 x 265mm floorbox. 416
FLOOR SYSTEMS
SCREEDED
Screed System
